Rumoca User Guide

Rumoca is a Modelica compiler, simulator, and code generation toolkit written in Rust. It takes equation-based models of physical systems and turns them into simulations you can run from the command line, VS Code, or a browser — or into code for other ecosystems such as Python (SymPy, JAX, CasADi), C, Rust, and FMI.

What is Modelica?

Modelica is an open, equation-based language for modeling physical systems. Instead of writing step-by-step simulation code, you declare the equations that govern your system and let the compiler decide how to solve them.

The example below is a small hot-air-balloon model. It is live: edit the code, press ▶ Simulate to integrate it right here in your browser, or Show DAE to see the equation system the compiler produces. The editor has the same syntax highlighting, completion, and error checking as the Rumoca VS Code extension, powered by the same compiler running in WebAssembly.

model HotAirBalloon "Hot-air balloon warmed by a burner"
  parameter Real m = 320.0 "Balloon, basket, and passenger mass [kg]";
  parameter Real g = 9.81 "Gravity [m/s2]";
  parameter Real Tamb = 293.15 "Ambient air temperature [K]";
  parameter Real tau = 35.0 "Envelope cooling time constant [s]";
  parameter Real burnerHeat = 0.8 "Temperature rise from burner [K/s]";
  parameter Real liftPerKelvin = 130.0 "Buoyant lift per kelvin [N/K]";
  parameter Real drag = 240.0 "Vertical drag [N.s/m]";
  parameter Real targetHeight = 30.0 "Altitude where the burner switches off [m]";
  parameter Real fuelBurnTime = 28.0 "Fuel burn time with burner fully on [s]";
  Real h(start = 2.0) "Altitude [m]";
  Real v(start = 0.0) "Vertical speed [m/s]";
  Real T(start = 320.0) "Envelope air temperature [K]";
  Real fuel(start = 1.0) "Fuel fraction";
  Real fuelPercent "Fuel remaining [%]";
  Real burner "Burner command";
equation
  burner = if fuel > 0.0 then if h < targetHeight then 1.0 else 0.0 else 0.0;
  fuelPercent = if fuel > 0.0 then 100.0 * fuel else 0.0;
  der(fuel) = if burner > 0.0 then -1.0 / fuelBurnTime else 0.0;
  der(T) = burnerHeat * burner - (T - Tamb) / tau;
  der(h) = if h > 0.0 then v else if v > 0.0 then v else 0.0;
  m * der(v) = liftPerKelvin * (T - Tamb) - m * g - drag * v;
  annotation(experiment(StopTime = 70.0, Interval = 0.1, Solver = "rk-like"));
end HotAirBalloon;

// Render the balloon state as a small Three.js scene.
// Only the integrated states (h, v, T, fuel) are read; the algebraics
// `burner` and `fuelPercent` are recomputed from the states below so the
// viz works on every solver path (the GPU integrator returns states only
// and freezes algebraics).
api.plotSeries(['h', 'fuel']);
const { THREE } = await api.loadThree();
const h = api.series('h');
const fuel = api.series('fuel');
// burner = if fuel > 0 and h < targetHeight then 1 else 0 (model eqn);
// targetHeight matches the model parameter.
const targetHeight = 30.0;
const burner = h.map((hi, k) => (fuel[k] > 0.0 && hi < targetHeight) ? 1.0 : 0.0);

container.classList.add('rumoca-live-surface');
const host = document.createElement('div');
host.className = 'rumoca-live-surface-host';
container.appendChild(host);

const renderer = new THREE.WebGLRenderer({ antialias: true, preserveDrawingBuffer: true });
renderer.setPixelRatio(Math.min(window.devicePixelRatio || 1, 2));
renderer.setClearColor(0x8fd4ff, 1);
renderer.outputColorSpace = THREE.SRGBColorSpace;
host.appendChild(renderer.domElement);

const scene = new THREE.Scene();
scene.fog = new THREE.Fog(0x9fd5f1, 16, 42);
const camera = new THREE.PerspectiveCamera(42, 1, 0.1, 80);
camera.position.set(0, 4.2, 13.0);

scene.add(new THREE.HemisphereLight(0xfff2d4, 0x5a8a55, 1.6));
const sunLight = new THREE.DirectionalLight(0xffcc83, 2.4);
sunLight.position.set(5, 8, 4);
scene.add(sunLight);

const sun = new THREE.Mesh(
  new THREE.SphereGeometry(0.55, 32, 16),
  new THREE.MeshBasicMaterial({ color: 0xffe08a, fog: false })
);
sun.position.set(5.8, 5.2, -8);
scene.add(sun);

const ground = new THREE.Mesh(
  new THREE.PlaneGeometry(50, 35),
  new THREE.MeshStandardMaterial({ color: 0x7db35c, roughness: 0.9 })
);
ground.rotation.x = -Math.PI / 2;
ground.position.set(0, -2.4, -7);
scene.add(ground);

for (const [x, z, sx, sy, color] of [
  [-8, -13, 5.4, 1.5, 0x5f9461],
  [2, -14, 7.0, 1.9, 0x6fa76b],
  [10, -12, 4.8, 1.3, 0x8ab86e],
]) {
  const hill = new THREE.Mesh(
    new THREE.SphereGeometry(1, 24, 12),
    new THREE.MeshStandardMaterial({ color, roughness: 0.95, flatShading: true })
  );
  hill.scale.set(sx, sy, 2);
  hill.position.set(x, -2.0, z);
  scene.add(hill);
}

let randomSeed = 9;
function rand() {
  randomSeed = (randomSeed * 1664525 + 1013904223) >>> 0;
  return randomSeed / 4294967296;
}

function cloud(x, y, z, scale) {
  const group = new THREE.Group();
  const material = new THREE.MeshStandardMaterial({
    color: 0xffffff,
    roughness: 0.8,
    transparent: true,
    opacity: 0.82,
  });
  const puffCount = 5 + Math.floor(rand() * 4);
  for (let i = 0; i < puffCount; i++) {
    const puff = new THREE.Mesh(
      new THREE.SphereGeometry(0.55 + rand() * 0.55, 24, 16),
      material
    );
    puff.position.set((rand() - 0.5) * 1.7, (rand() - 0.35) * 0.45, (rand() - 0.5) * 0.35);
    puff.scale.set(1.0 + rand() * 0.9, 0.58 + rand() * 0.35, 0.82 + rand() * 0.45);
    group.add(puff);
  }
  group.position.set(x, y, z);
  group.scale.setScalar(scale);
  group.userData.speed = 0.0014 + rand() * 0.003;
  scene.add(group);
  return group;
}
const clouds = [];
for (let i = 0; i < 7; i++) {
  clouds.push(cloud(-7 + rand() * 14, 3.0 + rand() * 2.5, -4.5 - rand() * 5.5, 0.32 + rand() * 0.42));
}

function envelopeTexture() {
  const canvas = document.createElement('canvas');
  canvas.width = 512;
  canvas.height = 256;
  const ctx = canvas.getContext('2d');
  const colors = ['#2453d6', '#ffe2bd', '#2d60d8', '#ffd8aa'];
  const stripeWidth = canvas.width / 10;
  for (let i = 0; i < 10; i++) {
    const grad = ctx.createLinearGradient(i * stripeWidth, 0, (i + 1) * stripeWidth, 0);
    grad.addColorStop(0, '#173b9d');
    grad.addColorStop(0.16, colors[i % colors.length]);
    grad.addColorStop(0.58, colors[i % colors.length]);
    grad.addColorStop(1, '#173b9d');
    ctx.fillStyle = grad;
    ctx.fillRect(i * stripeWidth, 0, stripeWidth + 1, canvas.height);
  }
  ctx.globalAlpha = 0.28;
  ctx.fillStyle = '#ffffff';
  ctx.fillRect(canvas.width * 0.74, canvas.height * 0.12, 18, canvas.height * 0.52);
  ctx.globalAlpha = 1.0;
  const texture = new THREE.CanvasTexture(canvas);
  texture.colorSpace = THREE.SRGBColorSpace;
  return texture;
}

const balloon = new THREE.Group();
scene.add(balloon);

const envelopeProfile = [
  [0.14, 0.0],
  [0.44, 0.12],
  [0.72, 0.38],
  [1.08, 0.82],
  [1.55, 1.5],
  [2.02, 2.32],
  [2.3, 3.1],
  [2.24, 3.72],
  [1.9, 4.28],
  [1.3, 4.72],
  [0.62, 5.0],
  [0.06, 5.08],
].map(([radius, y]) => new THREE.Vector2(radius, y));
const envelope = new THREE.Mesh(
  new THREE.LatheGeometry(envelopeProfile, 160),
  new THREE.MeshStandardMaterial({ map: envelopeTexture(), roughness: 0.55 })
);
balloon.add(envelope);

const throat = new THREE.Mesh(
  new THREE.TorusGeometry(0.45, 0.08, 12, 40),
  new THREE.MeshStandardMaterial({ color: 0x1743b8, roughness: 0.6 })
);
throat.rotation.x = Math.PI / 2;
throat.position.y = 0.14;
balloon.add(throat);

const basketMaterial = new THREE.MeshStandardMaterial({ color: 0x8a5429, roughness: 0.8 });
const basket = new THREE.Mesh(new THREE.BoxGeometry(0.9, 0.55, 0.65), basketMaterial);
basket.position.y = -0.45;
balloon.add(basket);

const ropeMaterial = new THREE.LineBasicMaterial({ color: 0x463021 });
for (const x of [-0.38, 0.38]) {
  for (const z of [-0.28, 0.28]) {
    balloon.add(new THREE.Line(
      new THREE.BufferGeometry().setFromPoints([
        new THREE.Vector3(x, -0.16, z),
        new THREE.Vector3(x * 1.25, 0.2, z * 1.25),
      ]),
      ropeMaterial
    ));
  }
}

const flameLight = new THREE.PointLight(0xff7a1a, 0, 3.0);
flameLight.position.set(0, 0.38, 0);
balloon.add(flameLight);
const flame = new THREE.Mesh(
  new THREE.ConeGeometry(0.14, 0.45, 24),
  new THREE.MeshBasicMaterial({ color: 0xff7a1a, transparent: true, opacity: 0.85 })
);
flame.rotation.x = Math.PI;
flame.position.y = 0.38;
balloon.add(flame);

function bird(x, y, z, phase) {
  const positions = new Float32Array([
    0, 0, 0.5, 1.2, 0, 0, 0, 0, -0.5,
    0, 0, -0.5, -1.2, 0, 0, 0, 0, 0.5,
  ]);
  const geometry = new THREE.BufferGeometry();
  geometry.setAttribute('position', new THREE.BufferAttribute(positions, 3));
  geometry.computeBoundingSphere();
  const mesh = new THREE.Mesh(
    geometry,
    new THREE.MeshBasicMaterial({ color: 0xffffff, side: THREE.DoubleSide })
  );
  mesh.position.set(x, y, z);
  mesh.scale.setScalar(0.18 + rand() * 0.08);
  mesh.rotation.y = Math.PI * 0.5;
  mesh.userData = {
    homeX: x,
    homeY: y,
    phase,
    speed: 0.011 + rand() * 0.007,
    drift: 0.12 + rand() * 0.18,
    positions,
  };
  scene.add(mesh);
  return mesh;
}
const birds = [];
for (let i = 0; i < 9; i++) {
  birds.push(bird(-4.5 + rand() * 9, 3.9 + rand() * 1.5, -7.5 + rand() * 2.5, rand() * Math.PI * 2));
}

function resize() {
  const width = Math.max(320, Math.floor(host.clientWidth || 720));
  const height = Math.max(320, Math.min(520, Math.floor(width * 0.58)));
  renderer.setSize(width, height, false);
  camera.aspect = width / height;
  camera.updateProjectionMatrix();
}
new ResizeObserver(resize).observe(host);
resize();

api.addAnimation(times, (frame) => {
  const t = times[frame];
  const altitude = Math.max(0, h[frame] || 0);
  const burn = Math.max(0, Math.min(1, burner[frame] || 0));
  const fuelPercent = Math.max(0, Math.min(100, Math.round((fuel[frame] || 0) * 100)));
  balloon.position.set(0.5 * Math.sin(t * 0.16), -1.2 + altitude / 18, 0);
  balloon.rotation.z = burn * 0.05 * Math.sin(t * 0.8);
  envelope.scale.set(1 + burn * 0.02, 1 + burn * 0.03, 1 + burn * 0.02);
  flame.visible = burn > 0.12;
  flame.scale.setScalar(0.8 + burn * 0.8);
  flameLight.intensity = burn > 0.12 ? 2.0 + burn * 5.0 : 0;

  for (let i = 0; i < clouds.length; i++) {
    clouds[i].position.x += clouds[i].userData.speed;
    if (clouds[i].position.x > 7) clouds[i].position.x = -7;
  }
  for (let i = 0; i < birds.length; i++) {
    const bird = birds[i];
    bird.position.z += bird.userData.speed;
    if (bird.position.z > -2.0) bird.position.z = -8.0 - rand() * 1.5;
    bird.position.x = bird.userData.homeX + Math.sin(t * 0.7 + bird.userData.phase) * bird.userData.drift;
    bird.position.y = bird.userData.homeY + Math.sin(t * 1.1 + bird.userData.phase) * 0.08;
    const flap = Math.sin((bird.position.z + t) * 5.2 + bird.userData.phase) * 0.85;
    bird.userData.positions[4] = flap;
    bird.userData.positions[13] = flap;
    bird.geometry.attributes.position.needsUpdate = true;
  }

  camera.lookAt(balloon.position.x, balloon.position.y + 2.2, balloon.position.z);
  renderer.render(scene, camera);
  return `t = ${api.formatTick(times[frame])} s · fuel ${fuelPercent}%`;
}, 8000);

Note what you did not have to write: no integration loop, no state vector bookkeeping, no event logic. der(h) means the time derivative of h, and the compiler transforms the equations into a form a numerical solver can integrate.

What Rumoca Gives You

The Normal Workflow

1. Write or open a Modelica model (.mo file).
2. Configure any external Modelica package roots, such as the Modelica Standard Library (MSL).
3. Run a direct command (rumoca sim model.mo) or a colocated rumoca-scenario.toml scenario (rumoca sim -c rumoca-scenario.toml).
4. Inspect results in the CLI, VS Code, the browser viewer, or generated target output.

Project Status

Rumoca is in active development. It compiles and simulates a growing subset of Modelica, validated continuously against the Modelica Standard Library, but it is not yet a complete replacement for mature tools such as OpenModelica or Dymola. See Language Support Status for an honest description of what works today.

How This Book Is Organized

• Getting Started installs Rumoca and walks you through your first model.
• The Modelica Language explains equation-based modeling and what Rumoca supports.
• Tools covers the CLI, VS Code extension, playground, formatter, and linter.
• Simulation covers direct runs, scenario files, solvers, interactive simulation, and debugging.
• Code Generation covers built-in and custom targets.

Developers who want to understand or modify the compiler itself should read the companion Rumoca Dev Guide book.
